    V18345-1010221001 ABB Valve Positioner TZIDC Electro Pneumatic V18345

    Ask Lasest Price
    Brand Name : ABB
    Model Number : V18345-1010221001
    Certification : HART
    Price : USD760.00/EA
    Payment Terms : T/T, Alipay, Paypal
    Supply Ability : 100pcs per month
    Delivery Time : stock
    • Product Details
    • Company Profile

    V18345-1010221001 ABB Valve Positioner TZIDC Electro Pneumatic V18345

    Product Details:
    Manufacturer : ABB
    Product No. : V18345-1010221001

    V18345 - TZIDC
    Electro-Pneumatic Positioner, intelligent, configurable, with indicato
    and operator panel
    Case made of aluminum, varnished, with mechanical position indicator,
    r mounting to linear actuators acc. DIN / IEC 534 / NAMUR or to rotary
    ctuators acc. VDI / VDE 3845
    Input 4 ... 20 mA, two-wire, with connector plug for LKS adapter and F
    module for HART communication, FM / CSA, Double acting, fail freeze,
    ble: Thread 1/2-14 NPT, air pipe: Thread 1/4-18 NPT, Plug-in module fo
    analog position feedback, signal range 4 ... 20 mA, two-wire, Without
    tional Mechanical Kit for Digital Position Feedback, Standard Design (
    rnish / Coding).

    Product type : TZIDC Electro-Pneumatic Positioner
    V18345 : TZIDC = intelligent, configurable with indicator and operator panel
    Case / Mounting : 1 = Case made of aluminium, varnished,protection IP 65 (NEMA 4X) for mounting to linear actuators acc. to DIN/IEC 534 / NAMUR or to rotary actuators acc. to VDI/VDE 3845 also ready for integral mounting
    Input / communication port : 1 = Input 4...20 mA, two-wire with connector plug for LKS adapter
    Explosion protection : 0 = without
    Output / safe position (in case of an electrical power failure) : 1 = Single acting, fail freeze
    Connections : 2 = Cable: Thread 1/2-14 NPT, Air pipe: Thread 1/4-18 NPT
    Option modules for analog or digital position feedback : 1 = Plug-in module analog position feedback (sign. range 4 … 20 mA)
    Optional mechanical kit for digital position feedback : 0 = without
    Design (varnish / coding) : 1 = Standard
    Output signal (two-wire technology) Nominal range : 4 ... 20 mA
    Digital input : Control voltage 0 ... 5 V DC logical switching state "0" 11 ... 30 V DC logical switching state "1"
    Digital output (control circuit to DIN 19234/NAMUR) Supply voltage : 5 ... 11 V DC
    Supply pressure : 1.4 ... 6 bar (20 ... 90 psi)
    Air consumption : < 0.03 kg/h / 0.015 scfm (independent of supply pressure)
    Housing Material/Protections : Aluminum, protection class IP 65 / NEMA 4X
    Surface/color : Electrostatic dipping varnish with epoxy resin, stove-hardened. Case varnished black, RAL 9005, matte, housing cover Pantone 420.
    Pneumatic connections : Threads G 1/4 or 1/4-18 NPT
    Weight : 1.7 Kg
    Shipping Weight : 3 Kg
