3500/33-01-00 Bently Nevada Vibration Monitoring System 16-Channel Relay Module

    Buy cheap 3500/33-01-00 Bently Nevada Vibration Monitoring System 16-Channel Relay Module from wholesalers

    Buy cheap 3500/33-01-00 Bently Nevada Vibration Monitoring System 16-Channel Relay Module from wholesalers
    • Buy cheap 3500/33-01-00 Bently Nevada Vibration Monitoring System 16-Channel Relay Module from wholesalers
    • Buy cheap 3500/33-01-00 Bently Nevada Vibration Monitoring System 16-Channel Relay Module from wholesalers
    • Buy cheap 3500/33-01-00 Bently Nevada Vibration Monitoring System 16-Channel Relay Module from wholesalers
    • Buy cheap 3500/33-01-00 Bently Nevada Vibration Monitoring System 16-Channel Relay Module from wholesalers

    3500/33-01-00 Bently Nevada Vibration Monitoring System 16-Channel Relay Module

    Ask Lasest Price
    Brand Name : Bently Nevada
    Model Number : 3500/33-01-00
    Certification : ATEX
    Price : Negotiable
    Payment Terms : T/T, Allipay, paypal
    Supply Ability : 100pcs per month
    Delivery Time : 12-18 weeks
    • Product Details
    • Company Profile

    3500/33-01-00 Bently Nevada Vibration Monitoring System 16-Channel Relay Module

    Bently Nevada 3500/33-01-00 16-Channel Relay Module


    Description

    The 3500/33 16-Channel Relay Module is a full-height module that provides 16 relay outputs. You can place any number of 16-channel
    relay modules in any of the slots to the right of the Transient Data Interface (TDI) Module.
    Each output of the 3500/33 16-Channel Relay Module can be independently programmed to perform voting logic.
    Each relay of the module includes Alarm Drive Logic. Programming for the Alarm Drive Logic uses AND and OR logic and may use the
    following:

    • Alarming inputs (alert and danger statuses)
    • Not-OK
    • Individual Measured Variables from any monitor channel or any combination of monitor channels in the rack

    You can program the Alarm Drive using the 3500 Rack Configuration Software.


    Information

    3500/33 AA-BB
    A: Output Module
    01 16-Channel Relay Output Module
    02 16-Channel Failsafe Relay Output Module
    03 Low Current 16-Channel Relay Output Module
    04 Low Current 16-Channel Failsafe Relay Output Module
    B: Hazardous Area Approval Option
    00 None
    01 CSA / NRTL / C (Class 1, Division 2)
    02 ATEX / IECEx / CSA (Class 1, Zone 2)


    Spares

    149986-01Spare 16-Channel Relay Control Module
    149992-01Spare 16-Channel Relay Output Module
    149992-02Spare 16-Channel Failsafe Relay Output Module
    149992-03Spare 16-Channel Low Current Relay Output Module
    149992-04Spare 16-Channel Low Current Failsafe Relay Output Module
    04425545Grounding Wrist Strap (single use)
    162291Channel Relay Module User Guide


    Related Product Recommendation:

    135489-023500/53133819-02
    1900/65A3500/333500/60 133819-01
    3500/65-01-013500/91-01-01-013500/42M 140734-02
    3500/42 138700-013500/33-01-01330850-50-05
    330180-91-05128229-01126648-01
    3500/50 133434-01330703-000-070-10-02-00330180-X1-05
    3500/42 140471-01125388-01H330780-51-00
    125680-013500/15E3500/65 172115-01

    Frequently Asked Questions:

    Q: Does your goods are new and original?
    A: Yes, they are new and original.

    Q: How long warranty?
    A:One-year warranty.
