    3500/40M-01-00 Bently Nevada 3500 Proximitor I/O Module With Internal Terminations

    Ask Lasest Price
    Brand Name : Bently Nevada
    Model Number : 3500/40M-01-00
    Certification : ATEX
    Price : Negotiable
    Payment Terms : T/T, Allipay, paypal
    Supply Ability : 100pcs per month
    Delivery Time : 12-18 weeks
    • Product Details
    • Company Profile

    3500/40M-01-00 Bently Nevada 3500 Proximitor I/O Module With Internal Terminations

    Bently Nevada 3500/40M-01-00 Proximitor Monitor


    Description

    The 3500/40M Proximitor Monitor is a four-channel monitor that accepts input from Bently Nevada proximity transducers, conditions the signal to provide various vibration and position measurements, and compares the conditioned signals with user-programmable alarms. The user can
    program each channel of the 3500/40M with the 3500 Rack Configuration Software to perform any of the following functions:
    • Radial vibration • Eccentricity • REBAM

    • Thrust position • Differential expansion


    The primary purpose of the 3500/40M Proximitor Monitor is to provide the following:

    • Machinery protection by continuously comparing monitored parameters against configured alarm setpoints to drive alarms

    • Essential machine information for both operations and maintenance personnel


    Information

    Proximitor Monitor
    3500/40M - AA-BB
    • A: I/O Module Type
    01 Proximitor I/O Module with Internal Termination
    02 Proximitor I/O Module with External Terminations
    03 Proximitor I/O Module with Internal Barriers and Internal Terminations
    • B: Hazardous Area Approval Option
    00 None
    01 cNRTLus (Class 1, Division 2)
    02 ATEX / IECEx / CSA (Class 1, Zone 2)

    Cables
    3500 Transducer XDCR signal to External Termination (ET) Block Cable
    129525 - AAAA-BB
    • A: I/O Cable Length
    0005 5 feet 1.5 metres)
    0007 7 feet(2.1 metres)
    0010 10 feet(3.0 metres)
    0025 25 feet(7.6metres)
    0050 50 feet(15.2 metres)
    0100 100 feet(30.5 metres
    • B: Assembly Instructions
    01 Not assembled
    02 Assembled
