    Pepperl Fuchs NBN30-U4-A2 Inductive Sensor with Durable PA Sensing Face

    Ask Lasest Price
    Brand Name : PF
    Model Number : NBN30-U4-A2
    Certification : ATEX
    Price : USD98.00/PC
    Payment Terms : Alipay
    Supply Ability : 100pcs per month
    Delivery Time : 12-14 weeks
    • Product Details
    • Company Profile

    Pepperl Fuchs NBN30-U4-A2 Inductive Sensor with Durable PA Sensing Face

    Pepperl Fuchs Inductive sensor NBN30-U4-A2



    General specifications
    Switching functioncomplementary
    Output typePNP
    Rated operating distance30 mm
    Installationnon-flush
    Output polarityDC
    Assured operating distance0 ... 24.3 mm
    Reduction factor rAl0.33
    Reduction factor rCu0.31
    Reduction factor r3040.74
    Reduction factor rBrass0.38
    Output type4-wire
    Nominal ratings
    Operating voltage10 ... 30 V
    Switching frequency0 ... 230 Hz
    Hysteresistyp. 5 %
    Reverse polarity protectionreverse polarity protected
    Short-circuit protectionpulsing
    Voltage drop≤ 2 V
    Operating current0 ... 200 mA
    Off-state current0 ... 0.5 mA
    No-load supply current≤ 20 mA
    Time delay before availability80 ms
    Operating voltage indicatorLED, green
    Switching state indicatorLED, yellow
    Functional safety related parameters
    MTTFd1230 a
    Mission Time (TM)20 a
    Diagnostic Coverage (DC)0 %
    Compliance with standards and directives
    Standard conformity

    StandardsEN IEC 60947-5-2
    Approvals and certificates
    UL approvalcULus Listed, General Purpose
    CCC approvalCCC approval / marking not required for products rated ≤36 V
    Ambient conditions
    Ambient temperature-25 ... 85 °C (-13 ... 185 °F)
    Mechanical specifications
    Connection typescrew terminals
    Core cross sectionmax. 2.5 mm2
    Housing materialPA/metal with epoxy powder coating
    Sensing facePA
    Housing basemetal
    Degree of protectionIP68 / IP69K
    Mass225 g
    Dimensions

    Height40 mm

    Width40 mm

    Length118 mm
    NoteTightening torque: 1.8 Nm (housing)
